| Type | VDSM(V) | VDRM(V) | ITAV(A) | Tc(°C) | IT(RMS)(A) | ITSM(A) | VTO(A) | rT(mΩ) | di/dt(A/μsec) | Tq(μsec) | Rth(j-c)(K/kW) | Outline | Download PDF |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MS PERI TF2712CZ25 | 2500 | 2500 | 2712 | 55 | 4239 | 43000 | 1.30 | 0.16 | 350 | 55 | 9.9 | R |  |
| MS PERI TF3189CZ25 | 2500 | 2500 | 3189 | 55 | 5024 | 51000 | 1.30 | 0.16 | 350 | 55 | 7.8 | P | |
| MS PERI TF3290CZ25 | 2500 | 2500 | 3290 | 55 | 5165 | 48000 | 1.10 | 0.17 | 500 | 50 | 7.8 | P | |
| MS PERI TF3550CZ28 | 2500 | 2400 | 3550 | 55 | 5573 | 56000 | 1.16 | 0.16 | 1500 | 50 | 7.0 | L | |
| MS PERI TF4068CZ28 | 3000 | 2800 | 4068 | 55 | 6400 | 61155 | 1.14 | 0.16 | 200 | 85 | 5.7 | N | |
| MS PERI TF4484CZ28 | 2900 | 2800 | 4484 | 55 | 7040 | 72000 | 1.18 | 0.15 | 1500 | 60 | 5.0 | Q | |
